二氧化碳灭火器
Every carbon dioxide fire extinguisher carries our persistent pursuit of safety.
二氧化碳灭火器
Every carbon dioxide fire extinguisher carries our persistent pursuit of safety.
Advanced production equipment operates precisely, and a strict quality inspection system is like a tight safety net, ensuring that every fire extinguisher leaving the factory has excellent performance and reliable quality.
参数
| 序列号 | 气缸直径 | CO2 充满重量 | 液体容量 | 设计厚度 | 高度 | 空瓶重量 | 灭火器总重量 | 底部形状 | 材料 | 充气速率 | 水压试验压力 |
| 1 | Φ104 | 2kg | 3.0L | 2.0mm | 485(±10mm) | 3.8kg | 6.4kg | 凹底 | 34CrMo4 | 0.667 | 250bar |
| 2 | Φ116 | 2kg | 3.0L | 2.2mm | 395(±10mm) | 3.7kg | 6.3 kg | ||||
| 3 | Φ116 | 3kg | 4.5L | 2.2mm | 545(±10mm) | 5.0kg | 7.6kg | ||||
| 4 | Φ136 | 3kg | 4.5L | 2.6mm | 420(±10mm) | 4.9kg | 8.6kg | ||||
| 5 | Φ136 | 5kg | 7.5L | 2.6mm | 655(±10mm) | 7.6kg | 133kg | ||||
| 6 | Φ136 | 6kg | 9.0L | 2.6mm | 770(±10mm) | 9.2kg | 15.9kg | ||||
| 7 | Φ154 | 5kg | 7.5L | 3.0mm | 530(±10mm) | 8.3kg | 14.0kg | ||||
| 8 | Φ154 | 7kg | 10.5L | 3.0mm | 710(±10mm) | 11.1kg | 18.8kg | ||||
| 9 | Φ154 | 10kg | 15L | 3.0mm | 970(+10mm) | 15.1kg | 25.8kg | ||||
| 10 | Φ104 | 2kg | 3.0L | 2.0mm | 480(±10mm) | 3.8kg | 6.6kg | 凸底 | |||
| 11 | Φ136 | 5kg | 7.5L | 2.6mm | 670(±10mm) | 7.4kg | 13.5kg | ||||
| 12 | Φ104.5 | 2kg | 2.67L | 2.5mm | 430(±10mm) | 3.8kg | 6.4kg | 凹底 | 34CrMo4 | 0.75 | 315bar |
| 13 | Φ117 | 2kg | 2.67L | 2.8mm | 360(±10mm) | 3.9kg | 6.5kg | ||||
| 14 | Φ117 | 3kg | 4.0L | 2.8mm | 505(±10mm) | 5.1kg | 8.7kg | ||||
| 15 | Φ137 | 3.75kg | 5L | 3.3mm | 465(±10mm) | 6.5kg | 10.5kg | ||||
| 16 | Φ137 | 5kg | 6.7L | 3.3mm | 590(±10mm) | 8.0kg | 13.7kg | ||||
| 17 | Φ137 | 6kg | 8L | 3.3mm | 685(±10mm) | 9.4kg | 16.1kg | ||||
| 18 | Φ137 | 7.5kg | 10L | 3.3mm | 845(±10mm) | 11.5kg | 20.2kg | ||||
| 19 | Φ154 | 10kg | 13.5L | 3.7mm | 880(±10mm) | 14.5kg | 25.3kg | ||||
| 20 | Φ104.5 | 2kg | 2.67L | 2.5mm | 430(±10mm) | 3.8kg | 6.6kg | 凸底 | |||
| 21 | Φ137 | 5kg | 6.7L | 3.3mm | 605(±10mm) | 8.5kg | 14.6kg |
| Serial Number | Cylinder Diameter | CO2 Charging Weight | Water Capacity | Design Thickness | Height | Empty Cylinder Weight | Eextinguisher Total Weight | Bottom Shape | Material | Charging Rate | Hydrostatic Test Pressure |
| 1 | Φ114 | 2kg | 3L | 4.0mm | 420(±10mm) | 4.9kg | 7.5kg | Concave Bottom | CK45/45# | 0.667 | 50bar |
| 2 | Φ114 | 3kg | 4.5L | 4.0mm | 600(±10mm) | 5.9kg | 9.5kg | ||||
| 3 | Φ133 | 3kg | 4.5L | 4.0mm | 435(±10mm) | 6.8kg | 10.4kg | ||||
| 4 | Φ133 | 5kg | 7.5L | 4.0mm | 600(±10mm) | 9.5kg | 15.2kg | ||||
| 5 | Φ140 | 5kg | 7.5L | 4.5mm | 665(±10mm) | 10.4kg | 16.1kg | ||||
| 6 | Φ140 | 6kg | 9L | 4.5mm | 790(±10mm) | 12.3kg | 19.0kg | ||||
| 7 | Φ152 | 5kg | 7.5L | 5.0mm | 570(±10mm) | 10.3kg | 16.0kg | ||||
| 8 | Φ152 | 6kg | 9L | 5.0mm | 670(±10mm) | 11.8kg | 18.5kg | ||||
| 9 | Φ152 | 7kg | 10.5L | 5.0mm | 750(±10mm) | 13.2kg | 20.8kg | ||||
| 10 | Φ152 | 10kg | 15L | 5.0mm | 1030(±10mm) | 18.0kg | 28.7kg | ||||
| 11 | Φ159 | 4.5kg | 6.7L | 5.0mm | 490(±10mm) | 10.5kg | 15.7kg | ||||
| 12 | Φ159 | 6.8kg | 10.2L | 5.0mm | 690(±10mm) | 14.5kg | 22.0kg | ||||
| 13 | Φ159 | 10kg | 15L | 5.0mm | 970(±10mm) | 20.4kg | 31.5kg | ||||
| 14 | Φ152 | 6kg | 9L | 5.0mm | 700(±10mm) | 11.5kg | 18.9kg | Convex Bottom |
